60RZR-Meter

Higher value with lower operating costs

Ideal for applications to pour concrete such as:

  • Large construction sites, flat blocks and infrastructure projects

The 60RZR-Meter features a 6-arm placing boom with RZR-folding with maximum flexibility, thanks to 205° rotation angle at the last hinge

Logo of Lendertrax

Key Features

  • Putzmeister hydraulic circuit and the latest core pump technology for maximum efficiency and up to 45 % oil saving
  • Intuitive operation thanks to Ergonic® 3.0
  • All information on the display of the remote control. Complete control and all the information at the workplace at all times
  • Continuous delivery line with nominal diameter of DN 125/5"
  • Small support width with flexible support, space-saving structure
  • Robust and steady thanks to reinforced substructure, compact boom pedestal and TRDI support
  • Lower service costs with maintenance-free components and smaller quantities of operating fluids, consumables, etc.
  • Lower weight with TRDI support structure compared to the 63Z-Meter with TRDV support

General Information

  • Number of sections
    6
  • Boom Style
    RZR-Folding
  • Vertical Reach
    59.2 m
  • Horizontal Reach
    54.2 m
  • Reach from Front of Truck
    50.9 m
  • Reach Depth
    44.1 m
  • Unfolding Height
    13 m
  • Rotation
    365 degree
  • End Hose Length max.
    3 m
  • End hose - Diameter
    125 mm
  • Delivery Line (DN + Pressure)
    125/85 mm/bar
  • Outrigger spread L-R - front hydraulically extended out & down
    12.1 m
  • Outrigger spread L-R - rear hydraulically swing out & extend down
    10.99 m
  • Length x Width x Height
    14.6x2.50x4.0 mm
  • Front Axle Weight
    23,809 kg
  • Rear Axle Weight
    24,555 kg
  • Total Weight (approx.)
    48,363 kg
  • Wheelbase
    8,484 mm

Configuration

  • Material Cylinder Diameter-Stroke Length
    250/2100 mm
  • Output (piston side)
    190 m³/hr
  • Delivery Pressure (piston side)
    85 bar
  • Strokes (piston side)
    31
  • Material Cylinder Diameter-Stroke Length
    250/2100 mm
  • Output (piston side)
    170 m³/hr
  • Delivery Pressure (piston side)
    85 bar
  • Strokes (piston side)
    28
