M38-5
Next Generation of the Truck-Mounted Concrete Pump M38-5 - Maximum Flexibility on 3 Axles
Putzmeister M38-5 is the perfect truck-mounted concrete pump for medium to high-volume concrete pours. It can also be used for universal job sites. It is consistently efficient thanks to clever ergonomic design. It is also safer than before considering the current standards and guidelines. This truck mounted concrete pump can be mounted on Chassis of various manufacturers as well as on 3-axles and 4-axles chassis.
Link to Reach Forecast App for M38-5 with Ergonic3. EU Version
Key Features
- A gross weight of less than 26 t incl. sufficient reserves for payload and operating materials
- Steady 5-arm placing boom, thanks to intelligent laying of the delivery line and the harmonious development of the steel structure
- Efficient work through consistently clever ergonomic design
- Even better safety through closer consideration for current standards and guidelines
- Service-friendly as a result of its optimised accessibility and consistent bolted concept
- Lower service costs, thanks to maintenance-free components, fewer special components (e.g. only 2 standard delivery line bends) and lower volumes of operating materials (oil volume reduced by 30 %)
General Information
-
Unfolding Height' "
-
End Hose Length max.' "
Configuration
-
Material Cylinder Diameter-Stroke Length10/83 "
-
Output (piston side)222 yd³/hr
-
Delivery Pressure (piston side)1233 psi
-
Strokes (piston side)28
-
Material Cylinder Diameter-Stroke Length9
-
Output (rod side)209 yd³/hr
-
Output (piston side)141 yd³/hr
-
Delivery Pressure (rod side)1233 psi
-
Strokes (rod side)31
