47RZ-Meter

Increased Maneuverability end Ease of Use

If you are looking for a lightweight, high performance machine on 4 axles — the truck-mounted concrete pump M 47-5 is built for you. Weighing less than 70,500 pounds, the M 47-5 is one of the lightest in its class and provides a more than sufficient payload reserve.

It is ideal for application at medium to large sized sites as well as job sites that offer challenging setup situations.

The 47-5-Meter comes with the latest Ergonic®3.0 Control System.

Hauptmerkmale

  • Lower fuel consumption and reduced wear due to optimal engine speed
  • Fuel savings of up to 10%
  • Avoids unfavorable ranges
  • Designed with reduced gross vehicle weight, improved pipe layout and increased parts commonality

Allgemeine Informationen

  • Arme
    5
  • Faltungsart
    RZ-Fold
  • Reichhöhe
    46.1 m
  • Reichweite brutto
    41.1 m
  • Reichweite netto
    38 m
  • Reichtiefe
    32.4 m
  • Ausfalthöhe
    11.1 m
  • Schwenkbereich
    365 Grad
  • Endschlauchlänge
    3 m
  • Endschlauch Durchmesser
    125 mm
  • Förderleitung, Förderdruck max.
    125/5/85 mm/bar
  • Abstützbreite L-R - Vorne hydraulisch nach außen und nach unten ausfahrbar
    8.50 m
  • Abstützbreite L-R - hinten hydraulisch nach außen und nach unten ausfahrbar
    9.08 m
  • Länge x Breite x Höhe
    11.90 x 2.50 x 3.88 m
  • Gewicht Vorderachse
    14892 kg
  • Gewicht Hinterachse
    16914 kg
  • Gesamtgewicht (ca.)
    31806 kg
  • Radstand
    6756 mm

Konfiguration

  • Förderzylinder Durchmesser - Hublänge
    250/2100 mm
  • Fördermenge (bodenseitig)
    170 m³/hr
  • Förderdruck (kolbenseitig)
    85 bar
  • Hübe (bodenseitig)
    27
  • Förderzylinder Durchmesser - Hublänge
    230/2100 mm
  • Fördermenge (stangenseitig)
    160 m³/hr
  • Fördermenge (bodenseitig)
    108 m³/hr
  • Förderdruck (stangenseitig)
    85 bar
  • Hübe (stangenseitig)
    31
