P 718 TD - SD
Low-wear, compact powerful Concrete Pump for Fine Concrete
The P 718 TD or SD piston pump is ideally suited for conveying fine concrete up to a grain size of 1.25" (32 mm) and for working with shotcrete.
It is our most powerful machine of this kind to date – it boasts impressive performance data and is lightweight with a well thought-out and user-friendly design.
Available Chassis versions: Skid (S) or trailer (T)
Key Features
- Powerful 3-cylinder Deutz diesel engine compliant with the current COM III/D3A exhaust specifications
- 2-cylinder piston pump with hard-chromed delivery cylinders
- Large hopper 9.9 ft³ (280 l) with rubber collar and protective grid
- Piston pump unit extremely robust
- Chassis for road use
- Supporting feet for secure stability
Technical Details
General Information
-
Feed Hopper12.7 ft³
-
Output5.2-22.75 yd³/hr
-
Delivery Pressure986 psi
-
Horizontal Reach985 ft
-
Vertical Reach330 ft
-
Pumphydraulic , 2-cylinder
-
Strokes (piston side)27
-
Material Cylinder Diameter-Stroke Length6"/27.5"
-
Max. Aggregate Size1.25 "
Configuration
-
Enginediesel 3-cylinder
-
Engine Power46.2 hp
-
Engine Emissions3A
-
Weight6560 lbs
-
Length x Width x Height119"x57.5"x63"
-
Filling Height44 "
-
ChassisStationary
-
Engine3-cylinder Deutz diesel
-
Engine Power46.3 hp
-
Engine Emissions3A
-
Weight7611 lbs
-
Length x Width x Height182.3"x61.4"x70.5"
-
Filling Height46.5 "
-
ChassisTrailer version
